MIG-250CPM
| Function | MIG/Lift TIG/MMA/Flux |
| Output Current (A) | 35~280A @ MIG 10~280A @ MMA 10~280A @ TIG |
| Input Voltage (V) | 3 phase x 400V +/- 10% |
| max. Duty Cycle (%) | 60% - 280A @ MIG 25°C 60% - 250A @ MMA 25°C 40% - 280A @ MIG 40°C 40% - 250A @ MMA 40°C |
| NO-Load Voltage (V) | 58 |
| Power Factor | 0.93 |
| Protection Grade of Housing | IP23 |
| Electrode available | 1.6 / 2.5 / 3.2 / 4.0 / 5.0 mm |
| Wire diameter (mm) | 0.8 / 1.0 / 1.2 |
| Power Capacity (KVA) | 12 KVA |
| Dimension (cm) | 91 x 36 x 58 |
| Gross Weight (Kg) | 42.5 Kg |
